Docking station Dual Display
Docking station Dual Display
Docking station Dual Display
Docking station Dual Display
Generico

Replicador de Puertos USB 3.0 de Plugable Negro

Q1,286.00
Efectivo: Q1,253.00


CuotasPrecio
3Q441.68
6Q223.45
10Q135.64
12Q114.34

Docking station Dual Display Plugable UD-3900, 11 in 1, USB-C adapter, con puertos: 2x USB 3.0, 4 XUSB 2.0, Audio in/out, Ethernet, DVI, HDMI.

SKU: 649241924616 Categoría:

 In The Box

Item and Quantity Item Notes
1x USB 3.0 Universal Docking Station
1x Power Adapter Region-specific power outlet adapters are included for purchases in the UK, EU and AUS.
1x Passive DVI to HDMI adapter
1x Passive DVI to VGA adapter
1x Hybrid 2-in-1 USB 3.0 and USB-C cable
1x Quick Start Guide

 Video

Port  Placement Specification  Max Resolution and Refresh Rate  HDCP  Chipset
1x DVI (HDMI or VGA with Bundled Adapters)
(Output)		 Rear DVI-I (Single Link) 2048×1152 @ 60Hz
 Not Supported DL-3900
DisplayLink
1x HDMI
(Output)		 Rear HDMI 1.3 2560×1440 @ 50Hz
 Not Supported DL-3900
DisplayLink

 Audio

Port  Placement Connection  Max Bit Depth and Sample Rate  Signal Output  Channels  Chipset
HDMI
Output		 Rear DisplayLink HDMI Digital 2 DL-3900
DisplayLink
Headphone Jack
Output		 Front 3.5mm (TRS) Analog 2 DL-3900
DisplayLink
Microphone Jack
Input		 Front 3.5mm (TRS) Analog 2 DL-3900
DisplayLink

 Power

Port  Placement Power Host / Device  Connection Type  Notes Voltage  Amperage  Wattage
Power Supply Rear Device Region-specific Power Adapter UL 60950-1 Certified 5.0V 4.0A 20.0W

 USB To Devices

Port  Placement Version and Link Rate  Features  Voltage  Amperage  Wattage
2x USB-A Front USB 3.0 (5Gbps) 5V 900mA 4.5W
4x USB-A Rear USB 2.0 (480Mbps) 5V 500mA 2.5W

 Connection To Host

Port  Placement Version and Link Rate  Features
1x USB-A or USB-C Rear USB 3.0 (5Gbps)

 Wired Network

Port Placement Version and Link Rate Features  Chipset
DisplayLink Gigabit Ethernet Rear 1000BASE-T DL-3900
DisplayLink

 Included Cables

Port Type (Side 1) Cable Specification Port Type (Side 2) Cable Length External Power for Cable
1x Male USB-A or USB-C USB 3.0 (5Gbps) 1x Male USB-B (3.0) 1.02m/3.0ft No

Marca

Generico
